LumiScan DMC Reader

Download this manual for offline use (ZIP, 4.7 MB - HTML and Markdown, version 1.1.0.6)

Two metal parts on a conveyor, each marked with a Data Matrix code

Capture the marked parts. Printed labels or direct part marking.

Both Data Matrix codes outlined with their decoded content

Find and decode every code. ECC 200 Data Matrix, no template or training.

Example result
Codes	2
Text	HDV-4711-0425
Center	640, 312 px

Hand the result to your PLC. Content and position of each code.

LumiScan DMC Reader finds every ECC 200 Data Matrix code in a camera image and reports its content and position. Data Matrix is the square-module standard for part marking and direct part marking, so your PLC can trace serial numbers, batches and parts through production. The reader needs no template, training or configuration and runs on ctrlX OS or a Windows or Ubuntu PC.

For licensing, see Licence. Questions? See the FAQ. A problem or an error message? See Troubleshooting.
