LumiScan Cam Driver

Download this manual for offline use (ZIP, 9.7 MB - HTML and Markdown, version 2.2.1.10)
Two GenICam cameras connected to a ctrlX CORE

Connect your GenICam cameras. GigE Vision cameras on ctrlX CORE or a PC.
Camera image published as the node camera1/output/image

Each image lands on the Data Layer. Every other LumiScan app reads it from there.
Example: camera1/output/image

width

2448

height

2048

pixel-type

RGB8

is-connected

TRUE

Capture on command. Exposure, pixel format and trigger set per camera.

LumiScan Cam Driver connects Ethernet cameras that follow the GenICam standard and makes their images and camera functions available on the Data Layer. It finds and connects the cameras, captures images and sets exposure time, pixel format and other GenICam features. All other LumiScan apps take their images from it, on ctrlX OS or on a PC with Windows 11 or Ubuntu 24.04.

For licensing, see Licence. Questions or an error message? See the FAQ.
