LumiScan X

Download this manual for offline use (ZIP, 16.7 MB - HTML and Markdown, version 2.0.0.10)
Front of LumiScan X with 13 lenses

13 cameras in one housing. A light field camera array with 1.2 MP per camera.
Thirteen views combined into a depth map

Depth from 13 views. Passive 3D that copes with shiny surfaces and cluttered bins.
Point cloud coloured by depth

Point cloud and depth map. 1280 × 960, up to 6 frames per second.

LumiScan X is a light field 3D camera made of 13 synchronized 1.2 MPix cameras, built for robotics, automation and quality inspection. It measures depth passively from the 13 views, which helps with shiny surfaces and cluttered bins, and delivers a point cloud and depth map of 1280 × 960 points. Variants cover opening angles from 30° to 60°; it runs on 24 V DC or PoE and connects over Ethernet.

For licensing, see Licence. Questions? See the FAQ. A problem or an error message? See Troubleshooting.

The manual for the LumiScan X 3D camera. Use the navigation on the left to browse the individual chapters.
